LED lighting series
Free onsite assessment, energy saving solution and customization service. 【TEL】+886-7-815-9877#1401、1402E-Mali
T-bar LED light
- Replacing whole set of conventional T-bar fluorescent tube.
- Paired with specialized power supply offering quick start without flickering.
- Mercury-free with no mercury contamination factor.
- Long-lasting luminaire.
- Suitable for office and classroom with easy and quick installation.
Product Description
Other Product Description
T-Bar LED light luminaire.
T-Bar LED light product description
Technical specification
Detailed related technical specifications.
| Number of tubes |
LED T8-20 ft |
| Power |
40W |
| Color temperature |
3000K,6000K |
| Dimension mm |
600*600 |
| Thickness mm |
62mm |
| Weight kg |
3.4 |
| Luminaire Luminous flux (Im) |
3500 |
| Color rendering |
≧ 70 |
| Working voltage |
AC 100V~240V，50/60Hz |
| Power factor |
>0.85 |
| Luminaire efficiency |
>80% |
| Luminaire 1M illuminance (lux) |
Luminaire 1M illuminance (lux) |
| Beam angle |
135度 |
| Working temperature |
Working temperature |
